Features:
1. Designed for transportation of bulky, heavy weight items.
2. Light weight and durable, this well balanced, multi-purpose trailer is sturdily made.
3. Both body and floor are constructed from 1.6mm corrosion resistant electro-galvanised
sheet steel.
4. The floor is designed in a U-shape, for rigidity and strength.
5. Lugs on body sides for securing items.
6. Front rail.
7. Including spare wheel 195x14 inch

Dimensions
A    Height (over all) 1620 mm
B    Height (side) 760 mm
C    Length (body) 3000 mm
D    Length (over all) 4350 mm
E    Width (inside) 1720 mm
F    Width (over all) 2020 mm
G    Ground Clearance 220 mm

Technical Info
Tare Mass 420 kg
GVM 1420 kg
Pay Load 1000 kg
Brakes    Run - in
Axle Length 1530 mm
Axle Capacity 1600 kg
Leaf Springs 10 Blade
Wheels 185 x 14 inch

Subject to our general terms and conditions of supply and delivery. Technical data, pricing, dimensions, and weights are subject to change, due to a policy of continual product development. The illustrations are for reference only. Dimensions are in millimetres. Trailer World reserves the right to alter design and specifications without prior notice.
